Shield Tubing OLBF
Shield Tubing OLBF 铝箔型
- Al Foil
Product Overview
- Dark gray
- With aluminum foil (0.01mm)
- Perfect for sielding branch wires
Product Description
- Shield Tube – Snap type, Dark gray
- With aluminum foil (0.01mm)
- Can be easily installed without the need for tools
- Perfect for sielding branch wires
- RoHS compliant
| Item Name | OLBF | |
|---|---|---|
| Color | Dark Gray | |
| Sheet | Material | Flexible PVC + PET Film |
| Aluminum Foil 0.01mm | ||
| Thickness ※ | 0.25mm | |
| Additional Shielding Material | － | |
| Closure | Material | Polyacetal |
| Operating Temperature | -15℃ ～ 60℃ | |
| Diameter（Φ） | 10, 15, 20, 25, 30, 40, 50, 70, 100 | |
| Standard Length | 50m | |
| Note | Standard Type | |
※ Typical Value
Product Size
| Item Name | OLBF | ||
|---|---|---|---|
| Diameter（Φ） | Product Width （mm） | Effective Width （mm） | Approx. kg / Standard Length |
| 10 | 71 | 41 | 2.3 |
| 15 | 91 | 61 | 2.6 |
| 20 | 105 | 75 | 2.9 |
| 25 | 115 | 85 | 3.0 |
| 30 | 130 | 100 | 3.3 |
| 40 | 160 | 130 | 3.8 |
| 50 | 191 | 161 | 4.4 |
| 70 | 255 | 225 | 5.5 |
| 100 | 348 | 318 | 7.1 |
Standard Length
Φ15～100 50ｍ
