Ultra-Vanshield UV DD **-** J-03-D30
Ultra-Vanshield UV DD **-** J-03-D30 DD型
- Conductive Silicone
Product Overview
- Orange / Ivory white
- Dual-layer construction, conductive layer and non-conductive layer
- Waterproof seal and EMI shield
Product Description
- Dual elastomer shielding gasket – soft type
- Waterproof seal and EMI shielding
- Usable in a wide range of thermal enviroments
- For shielding and enhancing board-to-case conductivity
- RoHS compliant
| Item Name | UV DD＊＊-＊＊J-03-D30 | |
|---|---|---|
| Core | Material | Hardness 30A Tensile Silicone |
| Color | Gray | |
| Conductive Layer | Material | Silver Plated Aluminum |
| Silicone | ||
| Color | Ivory White | |
| Note | Soft Type （Hardness 30A） | |
Product Size
| Part No. | Size | ||||
|---|---|---|---|---|---|
| H1 | H2 | W | D | Standard Length | |
| (mm) | (mm) | (mm) | (mm) | (m) | |
| UV DD20-19J-03-D30 | 2.0 | 1.9 | 1.9 | （0.9） | 50 |
| UV DD33-29J-03-D30 | 3.3 | 3.2 | 2.9 | （1.2） | 50 |
Other Products 垫片
- Conductive Silicone
Ultra-VanshieldUV DD **-** J-03
- Orange / Ivory white
- Dual-layer construction, conductive layer and non-conductive layer
- Waterproof seal and EMI shield
- Conductive Fabric
Shield Foam 32PO
- Metallic gray
- Excellent Durability
- Improved mechanical property
- Conductive Fabric
Sield Foam 32TS - Variant Type
- Metallic gray
- 6 types, for example L shape, P shape, and D shape
- Halogen free
